808-H-0,3A | E-T-A
Magnetic circuit breaker, 1 pole, 0.3 A, 24 V (DC), solder connection, PCB mounting, IP30, 808-H-0,3A
Unit Price (€ / pc.)
32.6179 € *
Available: 0 pcs.
Leadtime: On Request **
Magnetic overcurrent circuit breaker, 808-H-0,3A, E-T-A
Single pole miniaturised magnetic circuit breaker with unique high-speed operating mechanism and push/pull on/off manual actuation. Fitted with electrically separate excitation and switching circuits, and one pair of auxiliary contacts which close when the main circuit is open. Also suitable for impulse operation. Designed for printed circuit board mounting. Low temperature sensitivity.
Applications
- Printed circuit boards and components
- Safety and control systems
Technical specifications
| Anschluss | Lötanschluss | |
| Befestigungsart | Leiterplattenmontage | |
| Betätiger | Druckknopf | |
| Nennspannung (DC) | 24 V | |
| Nennstrom | 0.3 A | |
| Polzahl | 1-polig | |
| Schutzart (IP) | IP30 |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85362010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
