EA-PS 2342-10B | EA-Elektroautomatik
Laboratory power supply, 42 VDC, outputs: 3 (10 A/10 A/4 A), 0 to 10 A, 332 W, 90-264 VAC, EA-PS 2342-10B
Unit Price (€ / pc.)
1,010.31 € *
Available: 5 pcs.
Leadtime: 2 Weeks **
Total Price:
1,010.31 € *
Price list
Quantity
Price per unit*
1 pcs.
1,010.31 €
5 pcs.
950.81 €
10 pcs.
855.61 €
*incl. VAT plus shipping costs
**Subject to prior sale
Triple laboratory power supplies, type PS 23.
With adjustable auxiliary output (3.0 to 6.0 V, 2.0 A, 12 W); Weight 212/332 W: 3.8/4.0 kg. Dimensions 212/332 W: W 282/282, H 82/90, D 243/260 mm.
Technical attributes (type, cable, output voltage, output current, weight): PS 2342–10B, 2 x 160 W, 2 x 0 to 42 V, 2 x 0 to 10 A
Technical specifications
| Anzahl der Ausgänge | 3 | |
| Ausgangsspannungsbereich | 42 VDC | |
| Ausgangsstrom | 10 A | |
| Ausgangsstrom 2 | 10 A | |
| Ausgangsstrom 3 | 4 A | |
| Breite | 282 mm | |
| Eingangsspannungsbereich | 90-264 VAC | |
| Höhe | 82 mm | |
| Leistung | 332 W | |
| Tiefe | 243 mm | |
| Wirkungsgrad | 85 % | |
| Ausgangsstrombereich | 0 bis 10 A |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85043121 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 6/8/11 |
| SVHC frei | Yes |
