4114 N/2H8P | ebm-papst
DC axial fan, 24 V, 119 x 119 x 38 mm, 570 m³/h, 78 dB, ball bearing, ebm-papst 4114 N/2H8P
Unit Price (€ / pc.)
196.0644 € *
Available: 9 pcs.
Leadtime: 8 Weeks **
Total Price:
196.06 € *
Price list
Quantity
Price per unit*
1 pcs.
196.0644 €
3 pcs.
190.1858 €
10 pcs.
183.6527 €
25 pcs.
178.7499 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC Axial fan, 4114 N/2H8P, EBM-PAPST
The 4114 N/2H8P is a brushless DC axial fan that is made for applications that require high performance cooling and protection from harsh weather conditions in outdoor and extreme environments.
Features
- Connection via single strands AWG 20, sensor and control strands AWG 22, UL1007, TR 64, stripped and tinned
- Protected against reverse polarity and blocking
- Direction of rotation right, viewed on the rotor
- Low operating noise at high back pressure
Technical specifications
| Version | DC axial fan | |
| Width | 119 mm | |
| speed | 11000 1/min | |
| Height | 119 mm | |
| Type of bearing | ball bearing | |
| Power consumption | 120 W | |
| Rated voltage | 24 V | |
| Sound pressure level | 78 db | |
| Depth | 38 mm | |
| Volume flow | 570 m³/h |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 84145925 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
