54304.1 | EFB-Elektronik
FO cable, multimode 62.5/125 µm, fibers: 4, OM1, LSZH, black, 54304.1
Order No.: 26P1160
EAN: 4049759072308
MPN:
54304.1
Unit Price (€ / mtr.)
0.9877 € *
Available: 0 mtr.
Available in 5 Days: 1,000 mtr.
Leadtime: On Request **
Fiber optic cable, 54304.1, EFB Elektronik
The 54304.1 is a universale cable for fixed installation indoor and outdoor in cable ducts, tubes and interconnections. Mechanical installation by winch is permitted only when using force meters with recording function. It is not suitable for underground laying (direct buried).
Technical specifications
| Anzahl der Fasern | 4 | |
| Außendurchmesser | 7 mm | |
| Farbe | schwarz | |
| Faserart | Multimode 62,5/125 µm | |
| Halogenfrei | Yes | |
| Kategorie | OM1 | |
| Material | LSZH | |
| Temperaturbereich (bewegt) | -20 °C bis 60 °C | |
| Temperaturbereich (unbewegt) | -5 °C bis 50 °C |
Download
Logistics
| Zolltarifnummer | 85447000 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
