54324.1 | EFB-Elektronik
FO cable, multimode 62.5/125 µm, fibers: 24, OM1, LSZH, black, 54324.1
Order No.: 26P1163
EAN: 4049759072339
MPN:
54324.1
Unit Price (€ / mtr.)
2.7608 € *
Available: 0 mtr.
Available in 5 Days: 1,000 mtr.
Leadtime: On Request **
Fiber optic cable, 54324.1, EFB Elektronik
The 54324.1 is a universale cable for fixed installation indoor and outdoor in cable ducts, tubes and interconnections. Mechanical installation by winch is permitted only when using force meters with recording function. It is not suitable for underground laying (direct buried).
Technical specifications
| Number of fibres | 24 | |
| Outer diameter | 7.5 mm | |
| Colour | black | |
| Chamfer type | multimode 62.5/125 µm | |
| Halogen free | Yes | |
| Category | OM1 | |
| Material | LSZH | |
| Temperature range (active) | -20 °C to 60 °C | |
| Temperature range (unmoved) | -5 °C to 50 °C |
Download
Logistics
| Customs tariff number | 85447000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
