108-40065 | ept
Female connector, type E, 48 pole, a-c-e, pitch 5.08 mm, solder pin, straight, tin-plated, 108-40065
Order No.: 52F7178
EAN: 4099891021641
MPN:
108-40065
Unit Price (€ / pc.)
4.2959 € *
Available: 0 pcs.
Leadtime: 9 Weeks **
Female connector DIN 41612/IEC 60603-2, type ept.
Requirements class 2; Quality class to DIN EN 60603-2: II/400 insertion/removal cycles. Insulation resistance: min. 1000 Gohm. Spring contact: double, double spring, two-sided. Insulator: PBTP, glass fiber-reinforced (UL 94 V-0), PC, glass fiber-reinforced (UL 94 V-1). Operating temperatures: –55 to +125 °C (design H = –65 to +125 °C). Certifications: UL.
FeFemale connector E, straight, with solder pins.
Pin: 1.0 x 1.0 mm (type 108-40074 = 0.6 mm).
Technical attributes (type, number of poles, contact row assignments, overall length): 108-40065, 48-pole, a-c-e, 20 mm, 94.9 mm
Technical specifications
| Anforderungsstufe | 2 | |
| Anschluss | Lötstift | |
| Bauform | E | |
| Kontaktart | Buchse | |
| Kontaktoberfläche | verzinnt | |
| Kontaktreihenbelegung | a-c-e | |
| Nennstrom | 5.6 A | |
| Orientierung | gerade | |
| Polzahl | 48-polig | |
| Rastermaß | 5.08 mm |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85389099 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
