108-40074 | ept
Female connector, type E, 48 pole, a-c-e, pitch 5.08 mm, solder pin, straight, 108-40074
Order No.: 52F7176
EAN: 4099891021634
MPN:
108-40074
Unit Price (€ / pc.)
7.9016 € *
Available: 47 pcs.
Leadtime: 5 Weeks **
Total Price:
7.90 € *
Price list
Quantity
Price per unit*
1 pcs.
7.9016 €
10 pcs.
6.9615 €
100 pcs.
6.1047 €
250 pcs.
5.8667 €
1000 pcs.
5.4859 €
*incl. VAT plus shipping costs
**Subject to prior sale
Female connector DIN 41612/IEC 60603-2, type ept.
Requirements class 2; Quality class to DIN EN 60603-2: II/400 insertion/removal cycles. Insulation resistance: min. 1000 Gohm. Spring contact: double, double spring, two-sided. Insulator: PBTP, glass fiber-reinforced (UL 94 V-0), PC, glass fiber-reinforced (UL 94 V-1). Operating temperatures: –55 to +125 °C (design H = –65 to +125 °C). Certifications: UL.
FeFemale connector E, straight, with solder pins.
Pin: 1.0 x 1.0 mm (type 108-40074 = 0.6 mm).
Technical attributes (type, number of poles, contact row assignments, overall length): 108-40074, 48-pole, a-c-e, 4.6 mm, 94.9 mm
Technical specifications
| Performance level | 2 | |
| Connection | solder pin | |
| Design | E | |
| Contact type | socket | |
| Contact row assignment | a-c-e | |
| Rated current | 5 A | |
| Orientation | straight | |
| Pin number | 48 pole | |
| Grid | 5.08 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85389099 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
