632115 | ESKA Erich Schweizer
Microfuses 6.3 x 32 mm, 630 mA, FF, 250 V (AC), 35 A breaking capacity, 632115
Unit Price (€ / pc.)
1.2495 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
Total Price:
1.25 € *
Price list
Quantity
Price per unit*
100 pcs.
1.2495 €
500 pcs.
1.1424 €
*incl. VAT plus shipping costs
**Subject to prior sale
Micro fuse, 632115, ESKA
The 632115 is a super quick-acting fuse that is designed to protect less sensitive components and is also used to protect cabling from melting or catching fire when an overload occurs.
Features
- Material glass tube transparent
- High rated voltage
- High breaking capacity
- Contact caps Brass, nickel plated
Technical specifications
| Version | microfuses | |
| Tripping characteristics | FF | |
| Breaking capacity | 35 A | |
| Design | 6.3 x 32 mm | |
| diameter | 6.3 mm | |
| Enclosure | glass tube | |
| Length | 32 mm | |
| Rated voltage (AC) | 250 V | |
| Rated current | 630 mA |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85361010 |
| Original Packaging | Carton with 10 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
