382276 | Extech
Laboratory power supply, 0 bis 30 VDC, outputs: 1 (20 A), 1 to 20 A, 230 VAC, 382276
Order No.: 22K0339
EAN: 4099891480271
MPN:
382276
Unit Price (€ / pc.)
507.1304 € *
Available: 0 pcs.
Leadtime: 2 Weeks **
Total Price:
507.13 € *
Price list
Quantity
Price per unit*
1 pcs.
507.1304 €
5 pcs.
456.4126 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power supply, 382276, extech
382276 is a DC switching power supply with an adjustable output from 0 to 30V/ 20A with two user-defined presets and a factory preset of 13.8V/20A. The power supply has two LED indicators, high RFI immunity, excellent EMI and a thermostatically controlled fan. Other features include over voltage, over temperature and short circuit protection. Works at 220V, 50/60Hz and comes complete with AC power cable.
Features
- Remote control for output voltage/current and on/off
- Two user-defined voltage and current presets and one 13.8V/20A factory preset
- Double 3-digit LED displays
- High RFI immunity and excellent EMI
Technical specifications
| Anzahl der Ausgänge | 1 | |
| Ausgangsspannungsbereich | 0 bis 30 VDC | |
| Ausgangsstrom | 20 A | |
| Breite | 200 mm | |
| Eingangsspannungsbereich | 230 VAC | |
| Höhe | 90 mm | |
| Tiefe | 215 mm | |
| Ausgangsstrombereich | 1 bis 20 A |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| SVHC frei | Yes |
