242408FPS-4R7M-01 | Fastron
Power choke, SMD 2424, 4.7 µH, 2.2 A, 242408FPS-4R7M-01
Unit Price (€ / pc.)
0.4165 € *
Available: 0 pcs.
Available in 4 Days: 1,700 pcs.
Leadtime: 18 Weeks **
SMD Shielded inductor, 242408FPS-4R7M-01, Fastron
This Inudctor provides good solderability with lead free tinned Terminals and is RoHS compliant. Suitable for circuits where high current saturation is critical. When small size matters, only 1.5 mm and higher profile for DC/DC converters e.g in portable devices or backlight for tablet displays.
Features
- High flux density ferrite core
- Magnetically shielded with a ferrite-epoxy resin
Technical specifications
| Ausführung | Leistungsdrossel | |
| Bauform | SMD 2424 | |
| Breite | 6.2 mm | |
| Gleichstrom | 2.2 A | |
| Gleichstromwiderstand | 52 mΩ | |
| Höhe | 2.2 mm | |
| Induktivität | 4.7 µH | |
| Länge | 6.2 mm | |
| Messfrequenz | 100 kHz | |
| Sättigungsstrom | 2.4 A | |
| Toleranz | ±20 % |
Download
Logistics
| Ursprungsland | MY |
| Zolltarifnummer | 85045000 |
| Originalverpackung | Bulk mit 1 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
