10052654 | Fischer Elektronik

Pin header, 40 pole, pitch 2.54 mm, straight, black, 10052654

Order No.: 58F7112
EAN: 4099891004385
MPN:
10052654
SL 17 SMD 058 40 G
Series: SL 17 SMD 058
10052654 Fischer Elektronik PCB Connection Systems Image 1
10052654 Fischer Elektronik PCB Connection Systems Image 2
Image may differ
Unit Price (€ / pc.)
7.3304 € *
Available: 51 pcs.
Leadtime: 12 Weeks **
Total Price:
7.33 € *
Price list
Quantity
Price per unit*
1 pcs.
7.3304 €
10 pcs.
6.7473 €
50 pcs.
6.1404 €
100 pcs.
5.5216 €
*incl. VAT plus shipping costs
**Subject to prior sale

Pin headers, gold-plated, for SMD mounting, type Fischer SL.

2.54 mm grid, for surface mounting, single and dual row, with 0.635 x 0.635 mm square pins; Rated current: 3.0 A. Rated voltage: 250 VAC. Test voltage: 2000 V. Insulator: PA 4.6 GF. Inflammability class: UL 94 V-0. Insulation resistance: at least 1000 Gohm. Contact material: CuSn alloy. Contact finish: 0.2 µm gold on nickel primer. Contact resistance: max. 5.0 Mohm. Operating temperatures: –40 to +163 °C (briefly up to +260 °C).

Angled by 90°, type SL.

Technical attributes (type, number of poles, version, dimension C): SL 17 SMD 058/40 G, 40–pole, dual–row, C 5.8 mm

Technical specifications
Anschluss SMD
Anschlussoberfläche verzinnt
Anzahl der Reihen 1
Ausführung Stiftleiste
Bestückung bestückt
Farbe schwarz
Kontaktart Stift
Kontaktoberfläche vergoldet
Nennspannung 250 V
Nennstrom 3 A
Orientierung gerade
Polzahl 40-polig
Rastermaß 2.54 mm
Logistics
Ursprungsland DE
Zolltarifnummer 85369095
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
