1 0237 232 029 | Flexa
Corrugated hose, inside Ø 28.4 mm, outside Ø 34.5 mm, BR 70 mm, PA, black, 1 0237 232 029
Unit Price (€ / mtr.)
14.6846 € *
Available: 0 mtr.
Leadtime: 2 Weeks **
Corrugated tubing, 1 0237 232 029, FLEXA
Protective all-plastic tubing that is internally and externally corrugated. It's thick-walled with a coarse profile.
Features
- High cross pressure strength
- Air and liquid tight
- Oil resistant up to + 80° C
- Benzine resistant
- Widely resistant to acids and solvents
- Free of silicone, cadmium, halogen
- Flame retardant
- Self-extinguishing
- UV-resistant
Technical specifications
| Outer diameter | 34.5 mm | |
| Bending radius | 70 mm | |
| Colour | black | |
| Flame-retardant | Yes | |
| Inner diameter | 28.4 mm | |
| Material | PA | |
| max. operating temperature | 150 °C | |
| min. operating temperature | -40 °C | |
| Degree of protection (IP) | IP68/IP69K |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 39173200 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
