FLUKE 124B/EU/S | Fluke
2-channel ScopeMeter FLUKE 124B/EU/S, 40 MHz, 4 GSa/s, 5.7" TFT, 8.75 ns
Unit Price (€ / pc.)
3,944.85 € *
Available: 0 pcs.
Leadtime: On Request **
ScopeMeter, 4755975, Fluke
The 120B Industrial ScopeMeter Series test instruments include innovative features that help technicians troubleshoot faster and get the answers they need to keep their systems up and running. View waveforms with Connect-and-View™ trigger and setup technology and automatically display associated numerical measurements with Fluke IntellaSet™ technology, without manual measurement setup. Recorder event detection captures elusive intermittent events and logs them for easy viewing and analysis.
Features
- Digital oscilloscope and multimeter with two inputs
- 40 MHz or 20 MHz oscilloscope bandwidth
- Two 5,000x true-rms digital multimeters
Technical specifications
| Sample Rate | 4 GSa/s | |
| Rise time | 8.75 s | |
| Number of channels | 2 | |
| Display | 5.7" TFT | |
| Version | ScopeMeter | |
| Bandwidth | 40 MHz | |
| Width | 132 mm | |
| Weight | 1.4 kg | |
| Height | 259 mm | |
| Category | CAT III, CAT IV | |
| Length | 55 mm |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 90302000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
