E-KSU316 | Frolyt

Bipolar electrolytic capacitor, 4.7 µF, 50 V (DC), ±20 %, radial, pitch 2.5 mm, Ø 5.5 mm, E-KSU316

Order No.: 12D732
EAN: 4099879871947
MPN:
E-KSU316
E-KSU316 4,7/50 5,0X12,0
Series: EKSU
Frolyt
E-KSU316 Frolyt Electrolytic Capacitors Image 1
E-KSU316 Frolyt Electrolytic Capacitors Image 2
Image may differ
Unit Price (€ / pc.)
1.2376 € *
Available: 3,454 pcs.
Leadtime: On Request **
Total Price:
1.24 € *
Price list
Quantity
Price per unit*
1 pcs.
1.2376 €
10 pcs.
0.7735 €
50 pcs.
0.6783 €
*incl. VAT plus shipping costs
**Subject to prior sale

Bipolar electrolytic capacitor, E-KSU316, Frolyt

Aluminum electrolytic capacitor

Features

  • Low-voltage-electrolytic capacitor
  • Small dimensions
  • Insulated/Non polarized
  • Pulse-proof
  • Service life 1000...2500 h/+105 °C
Technical specifications
Version bipolar
Design radial
diameter 5.5 mm
ESR (Equivalent Series Resistance) 47.41 Ω
Capacity 4.7 µF
Length 12 mm
max. operating temperature 85 °C
min. operating temperature -40 °C
Rated voltage (DC) 50 V
Grid 2.5 mm
Tolerance ±20 %
Logistics
Country of origin DE
Customs tariff number 85322200
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
