E-RSM334 | Frolyt

Electrolytic capacitor, 10 µF, 100 V (DC), ±20 %, SMD, pitch 4.5 mm, Ø 8.9 mm, E-RSM334

Order No.: 10D4180
EAN: 4099879865229
MPN:
E-RSM334
E-RSM334 10/100 8,9X10,0
Series: ERSM
Frolyt
E-RSM334 Frolyt Electrolytic Capacitors Image 1
E-RSM334 Frolyt Electrolytic Capacitors Image 2
Image may differ
Print
Key Specification:
Version polar
Capacity 10 µF
Rated voltage (DC) 100 V
Tolerance ±20 %
Show 6 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
0.4284 € *
Available: 0 pcs.
Leadtime: On Request **
Add to Cart
Total Price:
0.43 € *
*incl. VAT plus shipping costs
**Subject to prior sale
2700 pcs.
0.4284 €
Description
Technical specifications
Download
Logistics
Compliance
Variations

SMD aluminum electrolytic capacitor, type Frolyt ERSM.

For surface mounting, suitable for use at temperatures up to +105 °C to DIN IEC 60384-1
Technical specifications
Version polar
Design SMD
diameter 8.9 mm
ESR (Equivalent Series Resistance) 14.3 Ω
Capacity 10 µF
Length 10 mm
max. operating temperature 105 °C
min. operating temperature -55 °C
Rated voltage (DC) 100 V
Grid 4.5 mm
Tolerance ±20 %
Show similar products 0
Logistics
Country of origin DE
Customs tariff number 85322200
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
