SPL 400-40 | Gossen Metrawatt
Electronic load, 0 to 40 A, 400 W, 115-230 VAC, SPL 400-40
Unit Price (€ / pc.)
3,153.50 € *
Available: 0 pcs.
Available in 7 Days: 10 pcs.
Leadtime: 4 Weeks **
Electronic load, K853A, Gossen Metrawatt
The SPL Series Electronic Loads are high accuracy DC current sinks for use in research, development, production, service and education.
Features
- 4 operating modes: constant current, constant voltage, constant load, constant power
- High-speed sequence and transient measurement, short-circuit withstand, battery discharge and other auxiliary functions
- Programmable current rise and fall time, steep edges
- Several groups of parameters (device settings) and sequences (load profile) can be stored and retrieved.
Technical specifications
| Breite | 226 mm | |
| Eingangsspannungsbereich | 115-230 VAC | |
| Höhe | 110 mm | |
| Leistung | 400 W | |
| Tiefe | 414 mm | |
| Lastgleichspannung | 0 bis 80 V | |
| Lastgleichstrom | 0 bis 40 A | |
| Lastwiderstand | 0,02 bis 2000 Ω | |
| Ausgangsstrombereich | 0 bis 40 A |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85437090 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
