METRAHIT PM TECH (METRAHIT TECH) | Gossen Metrawatt
TRMS digital multimeter METRAHIT PM TECH (METRAHIT TECH), 10 A(DC), 10 A(AC), 1000 VDC, 1000 VAC, 60 nF to 600 μF, CAT III 1000 V, CAT IV 600 V
Unit Price (€ / pc.)
1,042.44 € *
Available: 0 pcs.
Available in 7 Days: 4 pcs.
Leadtime: 4 Weeks **
Multimeter, M253A, Gossen Metrawatt
The METRAHIT PM TECH is a universal multimeter of the METRAHIT Professional multimeter series. The high-end TRMS multimeters of the METRAHIT PM series: METRAHIT PM TECH, XTRA and PRIME are absolutely robust and reliable digital multimeters developed for professional use. The devices present themselves in an attractive design with housings made of impact-resistant plastic and are technically state of the art.
State-of-the-art quality measuring instruments with unique precision: 60,000 digits and 0.05% basic accuracy offer maximum reliability of results.
Features
- TRMS AC, AC+DC measurement up to 20 kHz for voltage and current
- Direct current measurement with increased accuracy 0.1% for measurements on 4-20 mA transmitters
- Wide range capacitance measurement
Technical specifications
| Anzeige Digits | 60000 | |
| Ausführung | Digital-Multimeter | |
| Echteffektivwertmessung (TRMS) möglich | Yes | |
| Kapazitätsbereich | 60 nF bis 600 μF | |
| max. Strommesswert (bei AC) | 10 A | |
| max. Strommesswert (bei DC) | 10 A | |
| max. Widerstandsmessbereich | 60 MΩ | |
| Spannungsmessbereich (AC) | 1000 V | |
| Spannungsmessbereich (DC) | 1000 V | |
| Überspannungskategorie | CAT III 1000 V, CAT IV 600 V |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 90303100 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
