GMH5130-GE | Greisinger
Greisinger pressure gauge, GMH5130-GE, 600027
Order No.: 19K9740
EAN: 4099891463502
MPN:
GMH5130-GE
600027
Unit Price (€ / pc.)
327.012 € *
Available: 0 pcs.
Leadtime: 1 Week **
Pressure meters, type Greisinger GMH 51.
For mobile applications, MIN/MAX memory, Hold/Auto-Hold, Auto-Off function, battery low and battery status indication, backlight (adjustable ON duration ), user-defined display unit
Display: 4 1/2-digit, backlit
Display range: - 19999 to +19999
Measuring frequency: 4 measurements/s or 1000 measurements/s
Tolerance: ±0.1 % FS
Adjustable mean value filter: 1.0 to 120 s
Degree of protection housing: IP 65/IP 67
Power supply: 2 x AAA batteries (included)
Dimensions: H 160, W 86, T 37 mm
Weight: approx. 250 g. Supplied with battery and protective sleeve.
With one sensor connection
Technical specifications
| Auflösung | 1 bar | |
| Ausführung | Druckmessgerät | |
| Genauigkeit | ±0,1 % | |
| max. Temperatur | 50 °C | |
| Messbereich | -1999 mbar bis 1000 bar | |
| min. Temperatur | -25 °C | |
| Relative Luftfeuchtigkeit | 0 % bis 95 % | |
| Schutzart (IP) | IP65/IP67 |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 90262020 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 6/8/11 |
| SVHC frei | Yes |
