GPD-4303S | GW Instek
Laboratory power supply, 30 VDC, outputs: 4 (3 A/3 A/3 A), 0 to 3 A, 195 W, 90-253 VAC, GPD-4303S
Unit Price (€ / pc.)
749.70 € *
Available: 0 pcs.
Leadtime: On Request **
Mains adapter, GPD-4303S, GW Instek
GW Instek GPD-4303S 200W Quadruple-Output Programmable Linear DC Power Supply, 30V DC, 3 Amp, 1mV, 1-milliamp Resolution. The GPD-X303S Series contain the superior technology and high quality which GW Instek had established through its long history of power supply design and manufacturing.The GPD-X303 Series offers digital panel control, large display, bright LED indicators, high output resolution, 4 sets of setup memory, USB remote control and smart cooling fan control. Additionally,the GPD-X303S Series provide easy operation,a wide selection of panel setting and operation,a wide selection of panel settings. All these features make the GPD-X303 Series the most proming new comer in the power supply maeket.
Technical specifications
| Number of outputs | 4 | |
| Output voltage DC | 30 VDC | |
| Output current | 3 A | |
| Output current 2 | 3 A | |
| Output current 3 | 3 A | |
| Width | 210 mm | |
| Input voltage AC | 90-253 VAC | |
| Height | 130 mm | |
| Power | 195 W | |
| Depth | 265 mm | |
| Range of Output Currence | 0 to 3 A |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85044095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
