GPS-1850D | GW Instek
Laboratory power supply, 18 VDC, outputs: 1 (5 A), 0 to 5 A, 90 W, 100-240 VAC, GPS-1850D
Unit Price (€ / pc.)
264.18 € *
Available: 0 pcs.
Leadtime: On Request **
Mains adapter, GPS-1850D, GW Instek
GW Instek GPS-1850D 90W Single-Output Linear DC Power Supply with Digital LED screen, 18V DC, 5 Amp. The GPS-Series are single output, 54 to 90W, linear DC power supplies. The GPS-Series include both analog and digital display meters with varying power outputs. The GPS-Series feature Overload and reverse polarity protection as well as high regulation and low ripple / noise that are maintained at 0.01% and < 1mVrms, respectively. Continuous or dynamic internal load selection accommodates applications such as pulsed current. Remote control terminals offer programming and operation from an external device.
Technical specifications
| Anzahl der Ausgänge | 1 | |
| Ausgangsspannungsbereich | 18 VDC | |
| Ausgangsstrom | 5 A | |
| Breite | 128 mm | |
| Eingangsspannungsbereich | 100-240 VAC | |
| Höhe | 145 mm | |
| Leistung | 90 W | |
| Tiefe | 285 mm | |
| Ausgangsstrombereich | 0 bis 5 A |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
