09670154707 | Harting
D-Sub socket, 15 pole, standard, equipped, straight, wire-wrap, 09670154707
Unit Price (€ / pc.)
11.5787 € *
Available: 50 pcs.
Leadtime: 4 Weeks **
Total Price:
11.58 € *
Price list
Quantity
Price per unit*
1 pcs.
11.5787 €
10 pcs.
10.6505 €
50 pcs.
9.6985 €
100 pcs.
8.7227 €
*incl. VAT plus shipping costs
**Subject to prior sale
D-Sub socket, 09670154707, HARTING
This D-sub connector is an industry standard for cable-to-board connectivity applications and also can be universally used as a device interface.
Features
- Material flammability class acc. to UL 94: V-0
- Metal shell: Plated steel
- Contact material: Copper alloy
- Performance level: 3
Applications
- For data transmission
- For signal applications
- For power applications
Technical specifications
| Performance level | 3 | |
| Version | Buchsenleiste | |
| Attachment (rear panel) | Durchgangsloch | |
| Additional parts | bestückt | |
| Contact connection | Wire-Wrap | |
| Assembly | gerade | |
| Pole image | Standard | |
| Pin number | 15-polig | |
| Grid | 2.54 mm | |
| Type of locking | Durchgangsloch |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Blei |
