111-00824 | HellermannTyton
Cable tie, PA, (L x W) 202 x 4.6 mm, bundle-Ø 1.5 to 50 mm, gray, -40 to 130 °C, 111-00824
Unit Price (€ / pc.)
1.2138 € *
Available: 70 pcs.
Leadtime: 1 Week **
Total Price:
1.21 € *
Price list
Quantity
Price per unit*
1 pcs.
1.2138 €
10 pcs.
1.0591 €
100 pcs.
0.9758 €
500 pcs.
0.9044 €
1000 pcs.
0.8449 €
*incl. VAT plus shipping costs
**Subject to prior sale
Cable tie inside serrated, 111-00824, HellermannTyton
This inside serrated cable tie is made from Polyamide 4.6. It can be applied in environments with continuous temperatures up to +195 °C which makes it suitable for applications where a broader temperature range is required.
Features
- Low smoke generation in the event of a fire
- Inside serrated cable tie offers strong hold around bundles
- Easy application either manually or with an application tool
Technical specifications
| Version | innenverzahnt | |
| Length | 202 mm | |
| Width | 4.6 mm | |
| Thickness | 1.2 mm | |
| min. Bundle diameter | 1.5 mm | |
| max. Bundle diameter | 50 mm | |
| Min holding force | 225 N | |
| Material | PA | |
| Colour | grau | |
| detachable closure | No | |
| Chemical resistant | No | |
| UV-resistant | No | |
| Halogen free | Yes | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 130 °C |
Download
Logistics
| Country of origin | SG |
| Customs tariff number | 39269097 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
