Heatshrink tubing, 2:1, (25.4/12.7 mm), PE, crosslinked, black, 300-73100

Order No.: 91F215
EAN: 4031026282800
MPN:
300-73100
TCN20-25,4/12,7
Series: TCN20
HellermannTyton
300-73100 HellermannTyton Heat Shrink Tubing Image 1
300-73100 HellermannTyton Heat Shrink Tubing Image 2
300-73100 HellermannTyton Heat Shrink Tubing Image 3
300-73100 HellermannTyton Heat Shrink Tubing Image 4
300-73100 HellermannTyton Heat Shrink Tubing Image 5
Image may differ
Print
Key Specification:
Shrinking rate 2:1
Inner diameter before shrinkage 25.4 mm
Inner diameter after shrinkage 12.7 mm
Length 30 m
min. operating temperature -55 °C
Show 10 variants
Download Datasheet Technical specifications
Unit Price (€ / mtr.)
12.0309 € *
Available: 60 mtr.
Leadtime: 1 Week **
Total Price:
12.03 € *
Price list
Quantity
Price per unit*
1 mtr.
12.0309 €
10 mtr.
10.5910 €
50 mtr.
9.8651 €
150 mtr.
9.4367 €
500 mtr.
8.9488 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

Heatshrink tubing, type HellermannTyton TCN20.

Self-extinguishing, good chemical and mechanical resistance
Technical specifications
Colour black
Inner diameter after shrinkage 12.7 mm
Inner diameter before shrinkage 25.4 mm
contains glue inside No
Length 30 m
Material PE, crosslinked
max. operating temperature 125 °C
min. operating temperature -55 °C
Shrinking rate 2:1
Shrinking temperature 100 °C
Wall thickness 0.9 mm
Show similar products 0
Logistics
Country of origin CN
Customs tariff number 39173200
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
