906975 | HELUKABEL

Ex Cable gland, M40, 48/52 mm, Clamping range 20 to 33 mm, IP66/IP68, metal, 906975

Order No.: 93F8778
EAN: 4060892350269
MPN:
906975
906975 HELUKABEL Cable Glands
Image may differ
Unit Price (€ / pc.)
26.7631 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
321.16 € *
*incl. VAT plus shipping costs
**Subject to prior sale
12 pcs.
26.7631 €

Cable gland, 906975, HELUKABEL

Nickel plated brass EX cable gland, Temperature range -40°C to +100°C, Protection class IP 66 / IP 68.

Features

  • Optimum strain relief through clamping lamella
  • Easy to assemble, time and cost savings
  • Large clamping areas
  • Explosive protection
Technical specifications
Ausführung Kabelverschraubung
Farbe metall
Gewindegröße M40
Material Messing, vernickelt
max. Klemmbereich 33 mm
max. Temperatur 100 °C
min. Klemmbereich 20 mm
min. Temperatur -40 °C
Schlüsselweite 48/52 mm
Schutzart (IP) IP66/IP68
Logistics
Zolltarifnummer 74122000
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
