98085 | HELUKABEL

Cable gland, M32, 41 mm, Clamping range 13 to 20 mm, IP68/IP69K, 98085

Order No.: 12H0923
EAN: 4060892368134
MPN:
98085
Series: HSK-INOX
98085 HELUKABEL Cable Glands
Image may differ
Unit Price (€ / pc.)
80.1108 € *
Available: 0 pcs.
Available in 5 Days: 5 pcs.
Leadtime: 6 Weeks **
Total Price:
400.55 € *
*incl. VAT plus shipping costs
**Subject to prior sale
5 pcs.
80.1108 €

Cable gland, 98085, HELUKABEL

Stainless steel cable gland, Temperature range -40°C to +100°C, Protection class IP 68 - 10 bar / IP 69K.

Features

  • Optimum strain relief through clamping lamella
  • Easy to assemble, time and cost savings

Applications

  • Machine and plant construction
  • Automation technology
  • Installation technology
Technical specifications
Version Kabelverschraubung
Thread size M32
Material Edelstahl
max. clamping range 20 mm
max. operating temperature 100 °C
min. clamping range 13 mm
min. operating temperature -40 °C
spanner size 41 mm
Degree of protection (IP) IP68/IP69K
Logistics
Customs tariff number 85389099
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
