14024 | HELUKABEL
PVC control line OZ-BL 12 x 1.5 mm², AWG 16, unshielded, blue, 14024
Unit Price (€ / mtr.)
5.593 € *
Available: 0 mtr.
Leadtime: On Request **
Control cable, 14024, HELUKABEL
The 14024 is a PVC control cable used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control. For explosion-endangered areas marked as intrinsically safe (blue) (ignition protection type -i-) flexible control or measurement cable for intrinsically safe systems in measurement and control technology. This system is not earthed and have a separate power circuit. This cable is not suitable for burial in the ground.
Features
- For intrinsically safe systems in explosion-endangered areas
- Largely oil resistant
Technical specifications
| Core insulation material | PVC | |
| Core colour sequence | black | |
| Number of cores | 12 | |
| Version | control line | |
| Outer diameter | 12.4 mm | |
| AWG cross-section | AWG 16 | |
| Colour | blue | |
| Halogen free | No | |
| Conductor category | CL.5 = fine stranded | |
| Cable material | copper, bright | |
| Cable cross-section | 1.5 mm² | |
| Material | PVC | |
| Rated voltage | 500 V | |
| Rated voltage U0 | 300 V | |
| Test voltage | 3 kV | |
| Shielding | unshielded | |
| Drag chain suitable | No | |
| Protective conductor available | No | |
| Temperature range (active) | -15 °C to 80 °C | |
| Temperature range (unmoved) | -40 °C to 80 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
