14090 | HELUKABEL

PVC control line OB-BL-PAAR-CY 6 x 0.75 mm², AWG 19, shielded, blue, 14090

Order No.: 93F8260
EAN: 4060892079757
MPN:
14090
Series: OB-BL-PAAR-CY
HELUKABEL
14090 HELUKABEL Control Cables
Image may differ
Unit Price (€ / mtr.)
3.1892 € *
Available: 0 mtr.
Leadtime: On Request **
Total Price:
3.19 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
3.1892 €

Control cable, 14090, HELUKABEL

PVC control cable used for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control. For explosion-endangered areas marked as intrinsically safe (blue) (ignition protection type -i-) flexible control or measurement cable for intrinsically safe systems in measurement and control technology. The screening guarantees an exact data transmission.

Features

  • Largely resistant to oil
Technical specifications
Core insulation material PVC
Number of cores 6
Version control line
Outer diameter 9.1 mm
AWG cross-section AWG 19
Colour blue
Halogen free No
Conductor category CL.5 = fine stranded
Cable material copper, bright
Cable cross-section 0.75 mm²
Material PVC
Test voltage 2 kV
Shielding shielded
Drag chain suitable No
Protective conductor available No
Temperature range (active) -10 °C to 80 °C
Temperature range (unmoved) -30 °C to 80 °C
Logistics
Customs tariff number 85444995
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
