24062 | HELUKABEL
PVC connection line MULTISPEED 500-PVC 18 G 0.75 mm², AWG 19, unshielded, black, 24062
Unit Price (€ / mtr.)
8.6275 € *
Available: 0 mtr.
Leadtime: On Request **
Connecting cable, 24062, HELUKABEL
PVC drag chain cable is used when extreme demands are imposed on the cable. Integrated materials and stranding techniques permit continuous use as highly flexible drag chain cables with long travelling distance capabilities at high or low speeds. For installation in dry and damp rooms, as well as outdoors with free movement, without tensile stress and without forced motion control capabilities. Suitable for frequent lifting and bending stress in machine and tool construction.
Features
- Low adhesion
- Highly restistant to alternate bending strength
Technical specifications
| Aderisolationsmaterial | PP | |
| Anzahl der Adern | 18 | |
| Ausführung | Anschlussleitung | |
| Außendurchmesser | 13.9 mm | |
| AWG-Leiterquerschnitt | AWG 19 | |
| Farbe | schwarz | |
| Halogenfrei | No | |
| Leitermaterial | Kupfer, blank | |
| Leiterquerschnitt | 0,75 mm² | |
| Material | PVC | |
| Nennspannung | 500 V | |
| Nennspannung U0 | 300 V | |
| Prüfspannung | 3 kV | |
| Schirmung | ungeschirmt | |
| Schleppkettentauglich | Yes | |
| Schutzleiter vorhanden | Yes | |
| Temperaturbereich (bewegt) | -15 °C bis 80 °C | |
| Temperaturbereich (unbewegt) | -30 °C bis 80 °C |
Download
Logistics
| Zolltarifnummer | 85444995 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
