26144 | HELUKABEL
Thermoplastic control line KOMPOFLEX JZ-500 12 G 0.75 mm², AWG 19, unshielded, black, 26144
Unit Price (€ / mtr.)
7.4613 € *
Available: 0 mtr.
Leadtime: On Request **
Control cable, 26144, HELUKABEL
Extremly robust universal cable. This cable is specially installed in rubbish, sewage-treatment plants, composting works, animal stalls and greenhouses. Suitable for installation for flexible use for medium mechanical, stresses with free movement without tensile stress or forced movements in dry, moist and wet rooms as well as outside.
Features
- Resistant to UV-radiation, Oxygene, Ozone, Microbes, Hydrofluoric acid, Hydrochloric acid and diluted sulfuric acid
- Low adhesion
Technical specifications
| Core insulation material | thermoplastic | |
| Number of cores | 12 | |
| Version | control line | |
| Outer diameter | 9.9 mm | |
| AWG cross-section | AWG 19 | |
| Colour | black | |
| Halogen free | Yes | |
| Conductor category | CL.5 = fine stranded | |
| Cable material | copper, tin-plated | |
| Cable cross-section | 0.75 mm² | |
| Material | thermoplastic | |
| Rated voltage | 500 V | |
| Rated voltage U0 | 300 V | |
| Test voltage | 3 kV | |
| Shielding | unshielded | |
| Drag chain suitable | No | |
| Protective conductor available | Yes | |
| Temperature range (active) | -30 °C to 90 °C | |
| Temperature range (unmoved) | -40 °C to 100 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
