52198 | HELUKABEL
PO control line HELUTHERM 145 MULTI-C 1 x 0.5 mm², AWG 20, shielded, black, 52198
Unit Price (€ / mtr.)
2.38 € *
Available: 0 mtr.
Leadtime: On Request **
Connection cable, 52198, HELUKABEL
The 52198 is a cross-linked, temperature-resistant control and connection cable with enhanced behavior in the event of fire; for connecting lights, heating devices, electrical machines, switchgear and distributors. The cable is weather, moisture, ozone and UV-resistant and is therefore suitable for outdoor use, e.g. in traffic control systems. In the event of fire, this halogen-free cable emits only a small amount of smoke and no corrosive gases. The low fire load significantly reduces the risk of toxic fire gases; consequential fire damage to control and monitoring systems and the concrete and steel structure of buildings and systems can be minimised.
Features
- Resistant to oil, UV radiation, ozone, weathering effects
- Abrasion-resistant, notch-resistant
- For outdoor use
- Halogen-free
Technical specifications
| Core insulation material | PO | |
| Number of cores | 1 | |
| Version | control line | |
| Outer diameter | 3.7 mm | |
| AWG cross-section | AWG 20 | |
| Colour | black | |
| Halogen free | Yes | |
| Conductor category | CL.5 = fine stranded | |
| Cable material | copper, tin-plated | |
| Cable cross-section | 0.5 mm² | |
| Material | PO | |
| Rated voltage | 500 V | |
| Rated voltage U0 | 300 V | |
| Test voltage | 3 kV | |
| Shielding | shielded | |
| Drag chain suitable | No | |
| Protective conductor available | No | |
| Temperature range (active) | -35 °C to 120 °C | |
| Temperature range (unmoved) | -55 °C to 145 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
