53419 | HELUKABEL
PE control line HELUTHERM 145 MULTI 10 G 0.75 mm², AWG 19, shielded, black, 53419
Unit Price (€ / mtr.)
11.6382 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Control cable, 53419, HELUKABEL
The 53419 is a cross-linked, temperature-resistant and halogen-free control and connection cable with enhanced behavior in case of fire; to connect lighting fixtures, heaters, electrical machinery, switching systems and distributors. Excellent high-temperature stability allows for a long service life. Resistant to weathering effects, moisture, ozone and UV radiation and therefore suitable for outdoor applications, e.g. traffic control systems. Low smoke development and no emission of corrosive gases in case of fire. Low fire load reduces risk of toxic fumes. The extent of damage to costly control and monitoring systems and the concrete and steel structures of buildings and plants due to fire can be reduced.
Technical specifications
| Core insulation material | PO | |
| Number of cores | 10 | |
| Version | Steuerleitung | |
| Outer diameter | 11.1 mm | |
| AWG cross-section | AWG 19 | |
| Colour | schwarz | |
| Halogen free | Yes | |
| Conductor category | Kl.5 = feindrähtig | |
| Cable material | Kupfer, verzinnt | |
| Cable cross-section | 0,75 mm² | |
| Material | PE | |
| Rated voltage | 500 V | |
| Rated voltage U0 | 300 V | |
| Test voltage | 3 kV | |
| Shielding | geschirmt | |
| Drag chain suitable | No | |
| Protective conductor available | Yes | |
| Temperature range (active) | -35 °C bis 120 °C | |
| Temperature range (unmoved) | -55 °C bis 145 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
