63164 | HELUKABEL
PVC control line TRAYCONTROL 500 5 G 2.08 mm², AWG 14, unshielded, gray, 63164
Unit Price (€ / mtr.)
18.3498 € *
Available: 0 mtr.
Leadtime: On Request **
Control cable, 63164, HELUKABEL
The 63164 is a flexible, oil-resistant control cable. The special combination of TC-ER, PLTC-ER and ITC-ER allows this cableto be used as a connecting cable for industrial plant and machinery in accordance with NFPA 79. Approved for open, unprotected installation in cable trays to the machine. Its outstanding oil resistance (OIL RES I & II) guarantees a long service life for industrial applications in dry, damp and wet environments. Recommended applications: production lines, bottling plants, machine construction, switch cabinets, conveyor systems, packaging machines, automotive industry.
Features
- Highly flexible
- Easy to install
Technical specifications
| Aderisolationsmaterial | PVC | |
| Anzahl der Adern | 5 | |
| Ausführung | Steuerleitung | |
| Außendurchmesser | 10.9 mm | |
| AWG-Leiterquerschnitt | AWG 14 | |
| Farbe | grau | |
| Halogenfrei | No | |
| Leitermaterial | Kupfer, blank | |
| Leiterquerschnitt | 2,08 mm² | |
| Material | PVC | |
| Prüfspannung | 3 kV | |
| Schirmung | ungeschirmt | |
| Schleppkettentauglich | No | |
| Schutzleiter vorhanden | Yes | |
| Temperaturbereich (bewegt) | -5 °C bis 90 °C | |
| Temperaturbereich (unbewegt) | -40 °C bis 90 °C |
Download
Logistics
| Zolltarifnummer | 85444995 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
