17036 | HELUKABEL

PVC data cable, 8-wire, 1.5 mm², AWG 16, gray, 17036

Order No.: 93F6811
EAN: 4060892090462
MPN:
17036
Series: PAAR-CY-OZ
HELUKABEL
17036 HELUKABEL Data Cables
Image may differ
Unit Price (€ / mtr.)
5.2955 € *
Available: 0 mtr.
Leadtime: On Request **
Total Price:
5.30 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
5.2955 €

Data cable, 17036, HELUKABEL

The 17036 is a data cable suitable for flexible applications with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, however, not suitable for outdoor use. Used as a connection cable for signal, measurement and control technology, as well as in electronic engineering. Also applicable in pulse and data technology. Special areas of application include locations with high electromagnetic radiation, e.g. through adjacent lines.

Technical specifications
Core insulation material PVC
Number of cores 8
Version data cable
Outer diameter 13.5 mm
AWG cross-section AWG 16
Colour gray
Halogen free No
Cable material copper, bright
Cable cross-section 1.5 mm²
Material PVC
Shielding shielded
Drag chain suitable No
Temperature range (active) -15 °C to 80 °C
Temperature range (unmoved) -40 °C to 80 °C
Logistics
Customs tariff number 85444995
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
