43533 | HELUKABEL
PVC data cable, 8-wire, 0.75 mm², AWG 19, gray, 43533
Unit Price (€ / mtr.)
5.712 € *
Available: 0 mtr.
Leadtime: On Request **
Data cable, 43533, HELUKABEL
The 43533 is a data cable with overall pair screening and low capacities for installed terminals in medical and data technology. Application is also suitable in tool and machine construction, rolling mills and smelters, as well as traffic and process technology. EMC= Electromagnetic Compatibility; in order to optimise EMC properties, we recommend a double-sided and all-round large contact area of the copper braiding.
Technical specifications
| Core insulation material | PE | |
| Number of cores | 8 | |
| Version | data cable | |
| Outer diameter | 12.9 mm | |
| AWG cross-section | AWG 19 | |
| Colour | gray | |
| Halogen free | No | |
| Cable material | copper, bright | |
| Cable cross-section | 0.75 mm² | |
| Material | PVC | |
| Shielding | shielded | |
| Drag chain suitable | No | |
| Temperature range (active) | -5 °C to 80 °C | |
| Temperature range (unmoved) | -20 °C to 80 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
