59765 | HELUKABEL
PVC data cable, 14-wire, 0.154 mm², AWG 26, gray, 59765
Unit Price (€ / mtr.)
11.9238 € *
Available: 0 mtr.
Leadtime: On Request **
Data cable, 59765, HELUKABEL
The 59765 is a screened, twisted pair data and control cable. Cross-sections with PLTC-ER and ITC-ER approval suitable for open, unprotected installation in cable trays to the machine; their outstanding oil resistance (OIL RES I & II) makes them ideally suited as connecting and joining cables and also for control, signal and measuring systems in industrial plants. The flexible cable structure facilitates installation inside and outside of machines and switch cabinets. The double-screening with aluminium foil (100% coverage) and copper braid (approx. 85% coverage) guarantee superior EMC protection. Applications: tool machines, control panels, measuring devices, production automation, cable ducts, renewable energies.
Features
- Highly flexible
- Easy to install
- Oil resistant to OIL RES I & II
Technical specifications
| Aderisolationsmaterial | PVC | |
| Anzahl der Adern | 14 | |
| Ausführung | Datenkabel | |
| Außendurchmesser | 7.5 mm | |
| AWG-Leiterquerschnitt | AWG 26 | |
| Farbe | grau | |
| Halogenfrei | No | |
| Leitermaterial | Kupfer, verzinnt | |
| Leiterquerschnitt | 0,154 mm² | |
| Material | PVC | |
| Schirmung | geschirmt | |
| Schleppkettentauglich | No | |
| Temperaturbereich (unbewegt) | -25 °C bis 105 °C |
Download
Logistics
| Zolltarifnummer | 85444995 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
