62691 | HELUKABEL
PVC data cable, 15-wire, 0.963 mm², AWG 18, gray, 62691
Unit Price (€ / mtr.)
21.3248 € *
Available: 0 mtr.
Leadtime: On Request **
Data cable, 62691, HELUKABEL
The 62691 is a multi-core PVC data and control cable. Cross-sections with PLTC-ER and ITC-ER approval suitable for open, unprotected installation in cable trays to the machine; their outstanding oil resistance (OIL RES I & II) makes them ideally suited as connecting and joining cables and also for control, signal and measuring systems in industrial plants. The flexible cable structure facilitates installation inside and outside of machines and switch cabinets. Applications: tool machines, control panels, control and instrumentation technology, production automation, cable ducts, renewable energies.
Features
- Highly flexible
- Easy to install
- Oil resistant to OIL RES I & II
Technical specifications
| Core insulation material | PVC | |
| Number of cores | 15 | |
| Version | data cable | |
| Outer diameter | 13.5 mm | |
| AWG cross-section | AWG 18 | |
| Colour | gray | |
| Halogen free | No | |
| Cable material | copper, tin-plated | |
| Cable cross-section | 0.963 mm² | |
| Material | PVC | |
| Shielding | unshielded | |
| Drag chain suitable | No | |
| Temperature range (unmoved) | -25 °C to 105 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
