82822 | HELUKABEL
PUR data cable, 2-wire, 1.5 mm², black, 82822
Unit Price (€ / mtr.)
5.0337 € *
Available: 0 mtr.
Leadtime: On Request **
A-Bus cable, 82822, HELUKABEL
This A-Bus PUR cable is ideal for use in wet/dry areas thanks to its outstanding characteristics when exposed to common coolants/lubricants. This version can also be used in cable carriers (special installation conditions must be observed: place wide cable side on inside radius, use partitions and install flat/round cables separately).
Technical specifications
| Aderisolationsmaterial | Polyolefin | |
| Anzahl der Adern | 2 | |
| Ausführung | Datenkabel | |
| Farbe | schwarz | |
| Halogenfrei | Yes | |
| Leitermaterial | Kupfer, verzinnt | |
| Leiterquerschnitt | 1,5 mm² | |
| Material | PUR | |
| Schirmung | ungeschirmt | |
| Schleppkettentauglich | Yes | |
| Temperaturbereich (unbewegt) | -40 °C bis 80 °C |
Download
Logistics
| Zolltarifnummer | 85444995 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
