83817 | HELUKABEL
PVC data cable, 16-wire, 0.34 mm², AWG 22, gray, 83817
Unit Price (€ / mtr.)
7.4732 € *
Available: 0 mtr.
Leadtime: On Request **
Data cable, 83817, HELUKABEL
UL/CSA approved, screened, twisted pair data cable for use as a signal and measuring cable in machine tools, assembly lines, conveyor belts, plant construction, air conditioning devices, metallurgical plants, steel mills.
Features
- Resistant to: oil, solvents, acids, alkalis
Technical specifications
| Aderisolationsmaterial | PVC | |
| Anzahl der Adern | 16 | |
| Ausführung | Datenkabel | |
| Außendurchmesser | 10.4 mm | |
| AWG-Leiterquerschnitt | AWG 22 | |
| Farbe | grau | |
| Halogenfrei | No | |
| Leitermaterial | Kupfer, verzinnt | |
| Leiterquerschnitt | 0,34 mm² | |
| Material | PVC | |
| Schirmung | geschirmt | |
| Schleppkettentauglich | No | |
| Temperaturbereich (bewegt) | -10 °C bis 80 °C | |
| Temperaturbereich (unbewegt) | -40 °C bis 80 °C |
Download
Logistics
| Zolltarifnummer | 85444995 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
