83941 | HELUKABEL

PVC data cable, 4-wire, 0.34 mm², AWG 22, gray, 83941

Order No.: 93F8452
EAN: 4060892084782
MPN:
83941
HELUKABEL
83941 HELUKABEL Data Cables
Image may differ
Unit Price (€ / mtr.)
1.3804 € *
Available: 0 mtr.
Leadtime: On Request **
Total Price:
1.38 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
1.3804 €

Data cable, 83941, HELUKABEL

UL/CSA approved, twisted pair data cable for use as a signal and measuring cable in machine tools, assembly lines, conveyor belts, plant construction, air conditioning devices, metallurgical plants, steel mills.

Features

  • Resistant to: oil, solvents, acids, alkalis
Technical specifications
Core insulation material PVC
Number of cores 4
Version data cable
Outer diameter 5.8 mm
AWG cross-section AWG 22
Colour gray
Halogen free No
Cable material copper, tin-plated
Cable cross-section 0.34 mm²
Material PVC
Shielding unshielded
Drag chain suitable No
Temperature range (active) -10 °C to 80 °C
Temperature range (unmoved) -40 °C to 80 °C
Logistics
Customs tariff number 85444995
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
