15406 | HELUKABEL
PVC-switching strand, LifY, 0.5 mm², gray, outer Ø 2 mm, 15406
Unit Price (€ / mtr.)
0.8092 € *
Available: 100 mtr.
Leadtime: On Request **
Total Price:
0.81 € *
Price list
Quantity
Price per unit*
1 mtr.
0.8092 €
10 mtr.
0.7021 €
100 mtr.
0.6188 €
500 mtr.
0.5355 €
1000 mtr.
0.4879 €
*incl. VAT plus shipping costs
**Subject to prior sale
PVC single core, 15406, HELUKABEL
The 15406 is a highly flexible single core for connections in switch cabinet construction, measurement set-ups in laboratories, engineering and technical trainings as well as other applications that require increased bending properties. Also the materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers.
Technical specifications
| Aderisolationsmaterial | PVC | |
| Außendurchmesser | 2 mm | |
| Farbe | grau | |
| Halogenfrei | No | |
| Leiteraufbau | 132 x 0,07 mm | |
| Leiterklasse | Kl.6 = feinstdrähtig | |
| Leitermaterial | Kupfer, blank | |
| Leiterquerschnitt | 0,5 mm² | |
| Nennspannung | 500 V | |
| Nennspannung U0 | 300 V | |
| Prüfspannung | 2.5 kV | |
| Temperaturbereich (bewegt) | -15 °C bis 80 °C |
Download
Logistics
| Zolltarifnummer | 85444995 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
