24537 | HELUKABEL
PO motor connection cable TOPFLEX-EMV-UV-3-PLUS-2XSLCHK-J 6 x 3 x 2.5 mm² + 3 G 0.5 mm², AWG 14, shielded, black, 24537
Unit Price (€ / mtr.)
7.0567 € *
Available: 0 mtr.
Leadtime: On Request **
Motor connection cable, 24537, HELUKABEL
The 24537 is a motor connection cable for frequency converters used as a connecting cable for medium mechanical stress with fixed installation and occasional free movement in dry, damp or wet rooms, as well as outdoors. As a result of the permissible operating temperature of +90°C at the conductor, an enhanced current carrying capacity compared to PE insulated motor connection cables is permissible. Used in the automotive industry, food industry, environmental technology sector, packaging industry and in machine tools. Utilised as handling equipment for SIMOVERT drives in the industrial sector for pumps, fans, conveyor belts and air conditioning systems etc.
Features
- Resistant to UV radiation, weathering effects
- For outdoor use
- Halogen-free
- Low coupling resistance ensures good electromagnetic compatibility
Technical specifications
| Core insulation material | XLPE | |
| Number of cores | 6 | |
| Version | motor connection cable | |
| Outer diameter | 10.8 mm | |
| AWG cross-section | AWG 14 | |
| Colour | black | |
| Halogen free | Yes | |
| Conductor category | CL.5 = fine stranded | |
| Cable material | shielded | |
| Cable cross-section | 3 x 2.5 mm² + 3 G 0.5 mm² | |
| Material | PO | |
| Rated voltage | 1 kV | |
| Rated voltage U0 | 600 V | |
| Test voltage | 4 kV | |
| Shielding | shielded | |
| Temperature range (active) | -15 °C to 90 °C | |
| Temperature range (unmoved) | -40 °C to 90 °C |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
