931518500 | Hirschmann Automation and Control
Plug, 8 pole, solder cup, straight, 931518500
Nicht geeignet für Neudesigns, LTB: 30.06.2024
Unit Price (€ / pc.)
4.4030 € *
Available: 89 pcs.
DIN audio connector, plastic, type Hirschmann MAS 80 SN.
To EN 60130-09 and DIN 45326, solder terminals for conductors to max. 0.34 mm²; Contacts: tinned brass. Contact block: PA 66 to UL 94 V-2. Rated voltage: 34 V AC/DC. Rated current: 4.0 A. Degree of protection (IEC 60529): IP 30. Operating temperatures: - 20 to +60 °C.
DIN audio plugs, type MAS.
Straight plug with insulated grip, without screw lock; Housing material: PE.
Type: black
Technical specifications
| Ausführung | DIN-Stecker | |
| Bestückung | bestückt | |
| Gehäusematerial | Kunststoff | |
| Kabeldurchmesser | 5,5 mm | |
| Kontaktanschluss | Lötkelch | |
| Kontaktoberfläche | verzinnt | |
| Leiterquerschnitt | 0,34 mm² | |
| Montage | Kabelmontage | |
| Orientierung | gerade | |
| Polzahl | 8-polig |
Download
Logistics
| Ursprungsland | HU |
| Zolltarifnummer | 85366990 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
