933408100 | Hirschmann Automation and Control
Plug, M8, 3 pole, screw connection, screw locking, angled, 933408100
Unit Price (€ / pc.)
24.3474 € *
Available: 13 pcs.
Leadtime: 6 Weeks **
Total Price:
24.35 € *
Price list
Quantity
Price per unit*
1 pcs.
24.3474 €
10 pcs.
22.3958 €
25 pcs.
20.6108 €
50 pcs.
18.7544 €
*incl. VAT plus shipping costs
**Subject to prior sale
Circular connector M 8, type Hirschmann EL.
With screw lock; Rated voltage: 60 V AC/DC. Rated current: 3.0 A (2 A with 0.14 mm²). Contacts: gold-plated, CuZn. Pin diameter: 1.0 mm. Cage clamp strain relief. Conductor cross-section: max. 0.34 mm². Contact block and housing: PA. Degree of protection (IEC 60529): IP 67. Degree of soiling: 3. Housing and contact carrier inflammability: UL 94 V-2. Operating temperatures: - 25 to +70 °C. Cable bushing: M 9.5 x 1, cable entry max. 5.5 mm.
Angled cable plugs, type ELWIST.
Technical attributes (type, number of poles, screw lock (M 8), cable bushing): ELWIST 3008 V, 3-pole, M 8, M 9.5
Technical specifications
| Version | plug | |
| Additional parts | equipped | |
| Thread size | M8 | |
| Contact connection | screw connection | |
| contact surface | gold-plated | |
| Assembly | cable assembly | |
| Orientation | angled | |
| Pin number | 3 pole | |
| Degree of protection (IP) | IP67 | |
| Type of locking | screw locking |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
