LAS S G WS | Hirschmann Test & Measurement
4 mm plug, screw connection, 0.5-1.5 mm², CAT III, white, LAS S G WS
Unit Price (€ / pc.)
2.9988 € *
Available: 44 pcs.
Available in 6 Days: 50 pcs.
Leadtime: 1 Week **
Total Price:
3.00 € *
Price list
Quantity
Price per unit*
1 pcs.
2.9988 €
10 pcs.
2.6418 €
50 pcs.
2.3324 €
100 pcs.
2.2372 €
1000 pcs.
2.1063 €
*incl. VAT plus shipping costs
**Subject to prior sale
Laboratory connector, LAS S G WS, HIRSCHMANN
The LAS S G WS is a safety angled connector with screw connection for leads from 0.5 mm² to 1.5 mm² and the outer diameter of the lead is max. 4.2 mm.
Technical specifications
| Anschluss | Schraubanschluss | |
| Ausführung | Stecker | |
| Bemessungsspannung | 1000 V | |
| Bemessungsstrom | 24 A | |
| Berührungssicher | Yes | |
| Durchmesser | 4 mm | |
| Farbe | weiß | |
| Kontaktoberfläche | vernickelt | |
| Länge | 54.3 mm | |
| Leiterquerschnitt | 0,5-1,5 mm² | |
| max. Kabeldurchmesser | 4.2 mm | |
| Messkategorie | CAT III |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85366990 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
