PRUEF 1 SW | Hirschmann Test & Measurement
Miniature test probe, solder connection, 30 V, black, PRUEF 1 SW
Unit Price (€ / pc.)
3.2011 € *
Available: 21 pcs.
Available in 6 Days: 380 pcs.
Leadtime: On Request **
Total Price:
3.20 € *
Price list
Quantity
Price per unit*
1 pcs.
3.2011 €
20 pcs.
2.8203 €
100 pcs.
2.4752 €
500 pcs.
2.3681 €
1000 pcs.
2.2253 €
*incl. VAT plus shipping costs
**Subject to prior sale
Miniature test probes, type Hirschmann T & M PRUEF 1.
With step-on proof removable grip. For sampling the most intricate measuring points. The stainless steel tip easily penetrates insulation and oxide layers; Solder connection: up to 0.5 mm². Contact material: nickel-plated stainless steel. Rated voltage: 60 VDC. Contact resistance: 50 mohm. Operating temperatures: –25 to +60 °C.
Technical attributes (type, color): PRUEF 1, black
Technical specifications
| Connection | solder connection | |
| Colour | black | |
| Material Insulation | PVC | |
| Contact material | brass, nickel-plated | |
| Rated voltage | 30 V |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
