MLN 50/2,5 AU GN | Hirschmann Test & Measurement

Measuring lead with (4 mm plug, spring-loaded, straight) to (4 mm plug, spring-loaded, straight), 0.5 m, green, PVC, 2.5 mm², CAT O, MLN 50/2,5 AU GN

Order No.: 86F9689
EAN: 4099891948122
MPN:
MLN 50/2,5 AU GN
934 061-704
Series: MLN Au
Hirschmann Test & Measurement
MLN 50/2,5 AU GN Hirschmann Test & Measurement Test Leads
Image may differ
Unit Price (€ / pc.)
8.3776 € *
Available: 0 pcs.
Available in 6 Days: 100 pcs.
Leadtime: On Request **
Total Price:
8.38 € *
Price list
Quantity
Price per unit*
1 pcs.
8.3776 €
25 pcs.
7.3780 €
100 pcs.
6.7830 €
250 pcs.
6.3784 €
1000 pcs.
5.7834 €
*incl. VAT plus shipping costs
**Subject to prior sale

Measuring lead, MLN 50/2,5 AU GN, Hirschmann Test & Measurement

The MLN 50/2,5 AU GN is a measuring lead, at either end 4 mm diameter plug with caged spring and 4 mm diameter socket for tower construction. Gold-plated copper beryllium contact spring. Highly flexible, double insulated stranded lead, grip and lead shatter-proof. Built in colour indicator for easy identification of insulation damages.

Technical specifications
Connection (1) 4 mm plug, spring-loaded, straight
Connection (2) 4 mm plug, spring-loaded, straight
Rated Voltage 30 VAC/60 VDC
Rated current 32 A
Touch safe No
Colour green
Cable length 0.5 m
contact surface gold-plated
Cable cross-section 2.5 mm²
Material PVC
Rated category CAT O
Stackable Yes
Logistics
Country of origin DE
Customs tariff number 85444290
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
