OJ5005 | IFM electronic
OJ5005, Retro-reflective sensor, red light, light-infrared light, Lens type standard, (28 x 21)...(
Order No.: 82P7221
EAN: 4021179175487
MPN:
OJ5005
Unit Price (€ / pc.)
203.5019 € *
Available: 0 pcs.
Leadtime: 1 Week **
Total Price:
203.50 € *
Price list
Quantity
Price per unit*
1 pcs.
203.5019 €
3 pcs.
198.1826 €
*incl. VAT plus shipping costs
**Subject to prior sale
Retro-reflective sensor, OJ5005, IFM electronic
Features
- Particularly compact housing for use where space is restricted
- Very long range
- Simple alignment due to visible red light
- Intuitive setting of sensitivity and output function
- Easy mounting by clipping onto a mounting base
Technical specifications
| Connection | M8-connector | |
| Version | reflecting light barrier | |
| Output | NPN | |
| Design | A | |
| Detecting distance | 2 m | |
| Switching logic | light ON/dark ON | |
| Degree of protection (IP) | IP67 | |
| Voltage | 10-30 VDC | |
| Power supply | 22 mA |
Download
Logistics
| Country of origin | SG |
| Customs tariff number | 85365019 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
