IFC276 | IFM electronic
Inductive sensor, PNP, flush mounting M12, flush, 1 Form A (N/O), 30 V (DC), 100 mA, IFC276
Order No.: 82P5416
EAN: 4021179315326
MPN:
IFC276
Unit Price (€ / pc.)
84.2401 € *
Available: 0 pcs.
Leadtime: 1 Week **
Total Price:
84.24 € *
Price list
Quantity
Price per unit*
1 pcs.
84.2401 €
3 pcs.
80.5868 €
5 pcs.
77.2429 €
*incl. VAT plus shipping costs
**Subject to prior sale
Inductive sensor, IFC276, IFM electronic
Features
- For use in machine tools and metalworking
- Resistant to oils and coolants
- Metal sensing face for heavy duty
- Clearly visible indication of the switching status by LED
- Safe detection due to large sensing range and low sensor tolerances
Technical specifications
| Connection | M12-Steckverbinder | |
| Version | PNP | |
| Detecting distance | 4 mm | |
| Length | 70 mm | |
| Assembly | Einbaumontage M12, bündig | |
| Product type | Induktiver Sensor | |
| Latching switching function | 1 Schließer | |
| Switching Voltage (DC) | 30 V | |
| switching current | 100 mA | |
| Degree of protection (IP) | IP65/IP66/IP67/IP68/IP69K |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85365019 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
