54408.1L-CPR | INFRALAN
FO cable, singlemode 9/125 µm, fibers: 8, G657A1, LSZH, black, 54408.1L-CPR
Order No.: 26P1165
EAN: 4049759180515
MPN:
54408.1L-CPR
Unit Price (€ / mtr.)
0.7616 € *
Available: 0 mtr.
Available in 5 Days: 1,000 mtr.
Leadtime: On Request **
Fiber optic cable, 54408.1L-CPR, INFRALAN
The 54408.1L-CPR is a universale cable for fixed installation indoor and outdoor in cable ducts, tubes and interconnections. Mechanical installation by winch is permitted only when using force meters with recording function. It is not suitable for underground laying (direct buried).
Technical specifications
| Anzahl der Fasern | 8 | |
| Außendurchmesser | 7 mm | |
| Farbe | schwarz | |
| Faserart | Singlemode 9/125 µm | |
| Halogenfrei | Yes | |
| Kategorie | G657.A1 | |
| Material | LSZH | |
| Temperaturbereich (bewegt) | -20 °C bis 60 °C | |
| Temperaturbereich (unbewegt) | -5 °C bis 50 °C |
Download
Logistics
| Zolltarifnummer | 85447000 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
