54424.1L-CPR | INFRALAN

FO cable, singlemode 9/125 µm, fibers: 24, G657A1, LSZH, black, 54424.1L-CPR

Order No.: 26P1167
EAN: 4049759180539
MPN:
54424.1L-CPR
INFRALAN
54424.1L-CPR INFRALAN Fiber Optic Cables Image 1
54424.1L-CPR INFRALAN Fiber Optic Cables Image 2
Image may differ
Unit Price (€ / mtr.)
1.2614 € *
Available: 0 mtr.
Available in 5 Days: 1,000 mtr.
Leadtime: On Request **
Total Price:
1.26 € *
*incl. VAT plus shipping costs
**Subject to prior sale
2000 mtr.
1.2614 €

Fiber optic cable, 54424.1L-CPR, INFRALAN

The 54424.1L-CPR is a universale cable for fixed installation indoor and outdoor in cable ducts, tubes and interconnections. Mechanical installation by winch is permitted only when using force meters with recording function. It is not suitable for underground laying (direct buried).

Technical specifications
Number of fibres 24
Outer diameter 7 mm
Colour black
Chamfer type singlemode 9/125 µm
Halogen free Yes
Category G657A1
Material LSZH
Temperature range (active) -20 °C to 60 °C
Temperature range (unmoved) -5 °C to 50 °C
Logistics
Customs tariff number 85447000
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
